User name Eric Voutier
Log entry time 16:09:16 on March 5,2000
Entry number 35646
keyword=Harp Scan
**********************************************
scanner # 6 TJ name=IHA1H03B
Wire combination H position V position
# 1 # 2 -1188.um -28.um
# 1 # 3 -1202.um -42.um
# 2 # 3 -1202.um -15.um
weighted average -1202.um -28.um
roll angle 1.025mr 0.059deg -0.350deg
Absolute beam h position: -1202.um (+ means at beam left)
Absolute beam v position: -28.um (+ means too high)
Horizontal sigma (um): 245.
Elliptic approximation:
(tilt angle is from horizontal axis to major axis)
Vertical sigma (um): 233.688
Ellipse tilt angle (deg. clockw.): 139.222
Ellipse major axis length (um) : 274.272
Ellipse minor axis length (um) : 198.177
**********************************************
FIGURE 1
