User name Eric Voutier
Log entry time 13:20:22 on March 9,2000
Entry number 35992
keyword=Harp scan #626 & #627
scanner # 6 TJ name=IHA1H03B
Wire combination H position V position
# 1 # 2 -434.um -131.um
# 1 # 3 -444.um -140.um
# 2 # 3 -444.um -121.um
weighted average -444.um -131.um
roll angle 0.721mr 0.041deg -0.350deg
Absolute beam h position: -444.um (+ means at beam left)
Absolute beam v position: -131.um (+ means too high)
Horizontal sigma (um): 99.
Elliptic approximation:
(tilt angle is from horizontal axis to major axis)
Vertical sigma (um): 100.9291
Ellipse tilt angle (deg. clockw.): 133.350
Ellipse major axis length (um) : 118.463
Ellipse minor axis length (um) : 76.6153
FIGURE 1
FIGURE 2
