User name M. Rvachev
Log entry time 20:44:01 on March17,2000
Entry number 36376
keyword=Harp scan with no raster
scanner # 5 TJ name=IHA1H03A
Wire combination H position V position
# 1 # 2 -2309.um 1308.um
# 1 # 3 -2210.um 1407.um
# 2 # 3 -2210.um 1209.um
weighted average -2210.um 1308.um
roll angle -7.447mr -0.427deg 0.000deg
Absolute beam h position: -2210.um (+ means at beam left)
Absolute beam v position: 1308.um (+ means too high)
Horizontal sigma (um): 100.
Elliptic approximation:
(tilt angle is from horizontal axis to major axis)
Vertical sigma (um): 150.828
Ellipse tilt angle (deg. clockw.): 90.0000
Ellipse major axis length (um) : 150.828
Ellipse minor axis length (um) : 100.4566
**********************************************
scanner # 6 TJ name=IHA1H03B
Wire combination H position V position
# 1 # 2 -327.um -93.um
# 1 # 3 -344.um -110.um
# 2 # 3 -344.um -77.um
weighted average -344.um -93.um
roll angle 1.276mr 0.073deg -0.350deg
Absolute beam h position: -344.um (+ means at beam left)
Absolute beam v position: -93.um (+ means too high)
Horizontal sigma (um): 76.
Elliptic approximation:
(tilt angle is from horizontal axis to major axis)
Vertical sigma (um): 93.0392
Ellipse tilt angle (deg. clockw.): 77.7024
Ellipse major axis length (um) : 93.8226
Ellipse minor axis length (um) : 74.6706
**********************************************
geographical # Jlab name read Chronological #
in the beam line on the file in the file
5 IHA1H03A 1
6 IHA1H03B 2
Target beam h position: -7.um (+ for beam left)
Target beam v position: -346.um (+ for too high)
Target beam h angle: -0.300mrad (+ for clockwise)
Target beam v slope: -0.225mrad (+ for ascending slope)
ARC energy measurement: can't find scanner # 1
Output saved in file:
../scan_658.data.log
FIGURE 1
